Feature
- The mobile boat hoists can perform 12 different movement functions, including straight, diagonal, lateral, in-place rotation, and Ackermann steering, to meet various working conditions. It has a 4% climbing capability.
- The mobile boat hoists use a fully hydraulic drive system with a built-in diesel generator for power, offering excellent mobility.
- The mobile boat hoists employ a hinged main end beam design to eliminate stress caused by uneven road surfaces during movement.
- The lifting mechanism uses a load-sensing hydraulic system with adjustable lifting points, maintaining synchronous lifting at multiple points while adjusting power output according to the load, thereby reducing overall energy consumption.
Technical Specification
| Rated capacity (t) | 100 | 150 | 200 | 300 | |
| Grounding specific pressure (kg/cm2) | 11.5 | 11 | 11.5 | 6.5 | |
| Climbing ability (m/min) | 2% | 4% | 4% | 4% | |
| Lifting speed (m/min) | Full load | 0~2 | 0~1 | 0~2 | 0~1 |
| Non-load | 0~5 | 0~4 | 0~3 | 0~3 | |
| Running speed (m/min) | Full load | 0~20 | 0~20 | 0~20 | 0～20 |
| Non-load | 0～35 | 0~35 | 0～35 | 0～35 | |
| Working temperature | -20℃~+50℃ | -20℃~+50℃ | -20C~+50℃ | -20C~+50℃ | |
